Padlock steel 83WP/63 EC660 ka. as per sample/code

Extreme 83WP/63

Hardened special steel makes this 63 mm wide padlock extremely secure. Drainage channels and a plastic coating make it weather-resistant. The Extreme 83WP/63 is robust – and also flexible thanks to the interchangeable cylinder.

All variants for Extreme 83WP/63
Description
The Extreme 83WP/63 is a robust padlock that resists rusting even in severe weather conditions.
The lock is made of hardened special steel and owes its weather resistance to a plastic coating that encloses the entire lock body. Additional drainage channels make the padlock extremely weather-resistant. In addition, a protective cap shields the cylinder from moisture and dust. The strong steel shackle with NANO PROTECT™ coating also provides high corrosion protection and resists attacks with tools. This makes the 83WP/63 Extreme suitable for outdoor applications, for example, on gates and doors that are intended to protect valuable goods or machines as well as tools from unauthorised access.
Flexible thanks to keying alike: one key for several locks
You can adapt the lock to already existing bittings as the cylinder can be exchanged. The Extreme 83WP/63 combines robust safety, corrosion resistance and flexibility.

Technologies

  • Lock body and shackle made of hardened special steel
  • Hardened special steel shackle with NANO PROTECT™ coating for very high corrosion protection
  • Double bolted locking mechanism increases the security of the lock
  • 2 variants: with automatic locking by simply pressing down the shackle or with key retaining, i.e. locking only with a key (key retaining is set up by inserting the Z-bar)
  • Rekeyable: the cylinder can be exchanged and thus also adapted to existing bittings
  • Extremely weather-resistant: complete plastic coating and cylinder protection cap protect the lock from corrosion; drainage channels transport moisture that has penetrated the lock to the outside
  • Precision pin cylinder

Operation and use

  • Protection of items with a higher value and with a high risk of theft
  • Suitable for use on grilles, doors, gates, cabinets, toolboxes, cellar windows, sheds, switchgear, barriers, among other things
  • Flexible: can be adapted to different requirements in a short time thanks to its interchangeable cylinder
  • Can be combined keyed alike with various ABUS door cylinders
  • Ideal for extreme weather conditions (e.g. in sea and harbour areas, for securing on vehicles and boats/ships in outdoor use)

Downloads

General downloads:

Recycling

We have summarised for you which disposal information is important in your country.

Disposal & labelling of packaging
Specifications
Locking type: key
Width a: 64,5 mm
Vertical clearance c: 35 mm
Depth e: 35,5 mm
Weight: 552 g
Security Level Home Security: 9
Design: Technical drawing
Technical drawing
colour: black
Horizontal clearance b: 25 mm
Shackle diameter d: 11,5 mm
Height f: 111,5 mm
Keyed alike: No
