Door fitting KKZS700 FS

KKZS700 FS

Compact and resilient: Secure your fire doors against forced entry by third parties with fire door fitting for fire doors made of several layers of steel and with extra long cams.

  • Security Level 8/10 | ABUS GLOBAL PROTECTION STANDARD ® | A higher level means more security
All variants for KKZS700 FS
Description
Secure your fire doors with this compact door fitting.
Locking doors securely is a must. This also applies to fire doors. Time and again, however, the door cylinders stick out a little, making it easy for burglars to gain entry. Secure your fire doors with a door thickness of 37 to 47 millimetres against forced entry. The MPA-approved door fitting for fire doors has a steel core in the handle and is also made of several layers of steel that can withstand a pull of 2.5 tonnes. Extra long steel cams and hardened and tempered special screws increase protection against impacts. A steel insert in the inner shield serves as tear-off protection.
  • Made in Germany
Awards & Partners
Test seal Gesamtverband der deutschen Versicherungswirtschaft – Cologne, Germany
VdS anerkannt
Test seal Gesamtverband der deutschen Versicherungswirtschaft – Cologne, Germany

Awards & Partners

Technologies

  • Certified according to DIN EN 1906 SK2 und DIN 18 257 ES1, VdS approved, supervised by the MPA NRW (German institute for testing of materials
  • Short cover plate
  • Steel core in handle
  • Maximum resistance due to the layer construction: several bottom plates for maximum protection
  • High impact resistance: extra long steel cams, complete with tempered special screws (3 x M6)
  • An additional steel inset provides extra strong leverage/tear-off resistance
  • Integrated pulling protection with cylinder cover plus freely rotating special steel disc
  • Grip plate adjustable to DIN left and right doors
  • Spacing: 72 mm, square bolt: 9 mm
  • U-lever shape

Operation and use

  • For fire doors
  • Suitable for rebated and flush doors, left and right opening
  • Grip plate outside, handle inside
  • Suitable for door thicknesses of 37 - 47 mm

Variants

  • Finish: F1 (alu anodized)
  • Alternatively available as a handle/handle set

Downloads

General downloads:

Recycling

We have summarised for you which disposal information is important in your country.

Disposal & labelling of packaging
Specifications
colour: F1: Aluminum Nature
Cylinder protrusion: 10-18 mm
Beidseitig Drücker: No
pulling protection: Yes
Weight: 1045 g
Design: Technical drawing
Technical drawing
Distance measure: 72 mm
Interchangeable fitting: Yes
Door fitting for fire doors: Yes
Door type: Fire door
Security Level Home Security: 8
