Door fitting KKZS700 F2 SB

KKZS700

Dwellings reliably protected: This door fitting increases the security of flat doors. It impresses with its resistance to attempts to pull off the cylinder. High-quality materials put a stop to burglars.

  • Security Level 8/10 | ABUS GLOBAL PROTECTION STANDARD ® | A higher level means more security
All variants for KKZS700
Description
Protect your front door with this door fitting made of high-quality steel.
Burglars usually only have to make a few moves to gain access to your home. The reason: Door cylinders that stick out far. These can be pulled out. Make your flat door more secure with this door fitting in a compact design. The compact door hardware is particularly characterised by its high resistance to pulling attempts. In addition, extra-long steel cams and hardened and tempered special screws as well as the structure made of different steel layers increase your safety. The door hardware is suitable for flat doors with a door thickness of 37 to 47 millimetres. It is VdS and DIN certified.
  • Made in Germany
Awards & Partners
Test seal Gesamtverband der deutschen Versicherungswirtschaft – Cologne, Germany
VdS anerkannt
Test seal Gesamtverband der deutschen Versicherungswirtschaft – Cologne, Germany

Awards & Partners

Technologies

  • Certified according to DIN EN 1906 SK 2 and DIN 18 257 ES 1 ZA, VdS approved
  • Short cover plate
  • Maximum resistance due to the layer construction: several bottom plates for maximum protection
  • High impact resistance: extra long steel cams, complete with tempered special screws
  • An additional steel inset provides extra strong leverage/tear-off resistance
  • Integrated pulling protection with cylinder cover plus freely rotating special steel disc
  • Grip plate adjustable to DIN left and right doors
  • Spacing: 72 mm, square bolt: 8 mm

Operation and use

  • For apartment doors
  • Suitable for rebated and flush doors, left and right opening
  • Grip plate outside, handle inside
  • Suitable for door thicknesses of 37 - 47 mm
  • Mounting material for deviating door thicknesses can be supplied

Variants

  • Finishes: F1 (alu anodized), F2 (silver anodized), F3 (anodized brass), F4 (anodized bronze)
  • Alternatively available as a handle/handle set
  • Model fire protection (only in F1)

Downloads

General downloads:

Recycling

We have summarised for you which disposal information is important in your country.

Disposal & labelling of packaging
Specifications
colour: F2: Aluminum Nickel Silver
Cylinder protrusion: 10-18 mm
Beidseitig Drücker: No
pulling protection: Yes
Weight: 905 g
Design: Technical drawing
Technical drawing
Distance measure: 72 mm
Interchangeable fitting: Yes
Door fitting for fire doors: No
Door type: Apartment door
Security Level Home Security: 8
