Mortice lock TKZ40 Mortice lock TKZ40

TKZ40

For a safe feeling: The mortice lock locks automatically and can be opened from the inside without a key thanks to the anti-panic function.

All variants for TKZ40
Description
You have to be able to trust a lock. The mortice lock disappears completely into the door and locks automatically.
A safe feeling even when you are not at home. With the TKZ40 mortice lock you can rely on secure locking. After closing, the door is automatically locked. The lock convinces with high wear resistance. After mounting, it is invisible. Another practical feature is the anti-panic function, which allows the mortice lock to be opened from the inside without a key. It is suitable for flat entrance doors with a distance measurement of 72 millimetres.
  • Made in Germany

Technologies

  • For standard door cylinders (no free-turning cam needed)
  • Latch brass nickel-plated, square bolt malleable iron
  • High capacity of resistance by use of high quality materials
  • With anti-panic feature (can be opened with the handle from the inside)
  • Steel bolt with 21 mm protrusion
  • Stainless-steel forend

Operation and use

  • For internal doors/apartment doors
  • Self-locking when closing the door
  • Can be used right and left (forend and latch reversible)
  • Forend 20 x 235mm (round)

Variants

  • Finish: stainless steel

Downloads

General downloads:

Recycling

We have summarised for you which disposal information is important in your country.

Disposal & labelling of packaging
Specifications
colour: stainless steel
Distance measure: 72 mm
Depth lock case: 83 mm
Forend shape: round
Door type: Apartment door
Weight: 651 g
Design: Technical drawing
Technical drawing
Backset: 55 mm
Height lock case: 160 mm
Width forend: 20 mm
Lock control: Door cylinder
Opening direction: left/right
Security Level Home Security: 9
