Lever padlock 235Z Key

235Z

Robust and weatherproof: Our hasp 200 is suitable for bicycle baskets, barns or other outdoor applications. On request with side bar and chain for padlock.

All variants for 235Z
Colours for 235Z
Description
Our robust lever padlock 235Z is very suitable for protecting bicycle baskets, drawers, cupboards or barns against casual theft.
With this robust padlock, you can reliably secure your garden doors, bicycle baskets or other things outdoors. The lock is manufactured according to DIN 7465 and consists of a zinc plated chromated steel housing, which makes it particularly corrosion-resistant. The swivelling steel shackle can be closed by means of a pipe key - a key with a hollow blade. The keyhole is protected by a brass-plated cover. On request, the lock is available with a side bracket and chain to secure it.
  • Made in Germany

Technologies

  • Steel shackle protected against corrosion
  • Pipe keys
  • 40 mm: 4 levers
  • 50 mm: 6 levers
  • Key hole cover brass plated
  • Lock body made of galvanised steel, ideal for outside use
  • SKW: upon request also available with side shackle and chain according to fix the lock

Operation and use

  • To secure valuables/goods of low value or at a low risk of theft
  • Ideal for use in severe weather conditions (e.g. in coastal and port areas, to secure goods on vehicles and boats in outdoor use)
  • To lock e.g. cupboards, drawers, sheds, garden gates, bicycles baskets etc.

Variants

  • Sizes: 40, 50, 60 mm

Downloads

General downloads:

Recycling

We have summarised for you which disposal information is important in your country.

Disposal & labelling of packaging
Specifications
Locking type: key
colour: zinc plated
Width a: 40 mm
Vertical clearance c: 19 mm
Depth e: 20 mm
Weight: 77 g
Security Level Home Security: 3
Design: Technical drawing
Technical drawing
Security card: No
color of facets: silver
Horizontal clearance b: 22 mm
Shackle diameter d: 6 mm
Height f: 60 mm
Keyed alike: No
