Door fitting KLT512 FS

KLT512 FS

Reliable protection: You can effectively protect your fire doors from forced entry by criminals with this fire protection plate. It is made of multi-layer steel and is VdS-approved and DIN-certified.

  • Security Level 6/10 | ABUS GLOBAL PROTECTION STANDARD ® | A higher level means more security
All variants for KLT512 FS
Description
Fire doors can be effectively secured with this door fitting.
Unprofessionally secured doors pose a risk. Common vulnerability: Protruding door cylinders. These are usually quite easy for criminals to break off or drill. Therefore, protect your fire doors with a reliable guard. This fire protection plate consists of several steel plates and has extra long cams as well as hardened and tempered special screws. It can be fitted to fire doors with a door thickness of 37 to 47 millimetres and protects against breaking, drilling and pulling off the door cylinder. The door hardware is VdS-approved and DIN-certified.
  • Made in Germany
Awards & Partners
Test seal Gesamtverband der deutschen Versicherungswirtschaft – Cologne, Germany
VdS anerkannt
Test seal Gesamtverband der deutschen Versicherungswirtschaft – Cologne, Germany

Awards & Partners

Technologies

  • Certified according to DIN EN 1906 SK2 und DIN 18 257 ES1, VdS approved, supervised by the MPA NRW (German institute for testing of materials)
  • Steel core in handle
  • Maximum resistance due to the layer construction: several bottom plates for maximum protection
  • High impact resistance: extra long steel cams, complete with tempered special screws (3 x M6)
  • An additional steel inset provides extra strong leverage/tear-off resistance
  • Grip plate adjustable to DIN left and right doors
  • Spacing: 72 mm, square bolt: 9 mm
  • U-lever shape

Operation and use

  • For fire doors
  • Suitable for rebated and flush doors, left and right opening
  • Grip plate outside, handle inside
  • Suitable for door thicknesses of 37 - 47 mm

Variants

  • Finish: F1 (alu anodized)
  • Alternatively available as a handle/handle set

Downloads

General downloads:

Recycling

We have summarised for you which disposal information is important in your country.

Disposal & labelling of packaging
Specifications
colour: F1: Aluminum Nature
Cylinder protrusion: 12 mm
Beidseitig Drücker: No
pulling protection: No
Weight: 1628 g
Design: Technical drawing
Technical drawing
Distance measure: 72 mm
Interchangeable fitting: Yes
Door fitting for fire doors: Yes
Door type: Fire door
Security Level Home Security: 6
