TECTIQ Transponder Basic black MIFARE DESFire EV3 8K (Security UID)

Access only for authorised persons: RFID transponder (digital key) as a locking medium for ABUS TECTIQ locking systems. Additional use for time recording etc. possible as required.

Description



Unlock doors contactlessly
This battery-free RFID key fob with MIFARE® DESFire® technology is used for contactless locking and unlocking of TECTIQ door components. When held in front of the reader unit of a door component and checked by it, the door is unlocked if authorisation is granted.

Universally applicable
The RFID transponder can be used for other applications as required, such as time recording systems, photocopiers and canteen billing. Thanks to its robust design, the key fob is suitable for long-lasting use on key rings (resistant to dust, dirt and moisture). As a passive transponder, it does not require a battery.

Secure ease of use
Thanks to 13.56 MHz RFID technology, the components can be operated conveniently, securely readout-protected and contactless. The integrated, system-specific TECTIQ security application based on MIFARE® DESFire® technology offers maximum protection against copying and tampering.

Product advantages

  • RFID key fob (MIFARE® DESFire® EV3 8k)
  • Contactless opening of all ABUS TECTIQ door components (cylinders, fittings, wall readers, etc.)
  • Can also be used for other applications, e.g. photocopiers, canteen billing and time recording
  • Maximum copying and tampering protection thanks to additional integrated, system-specific ABUS security application
  • Robust design for long-lasting use on key rings (resists dust, dirt and moisture)
  • Simple assignment of transponder to personthanks to serial number on the back
  • Passive transponder without battery

Downloads

General downloads:

Recycling

We have summarised for you which disposal information is important in your country.

Disposal & labelling of packaging
Specifications
Area of application: Locking media for ABUS TECTIQ access control system with static UID
Colour: black
Design: Keyfob
Dimensions: 34,5 x 43,5 x 5 mm
IP protection class: 67
Item abbreviation: T-MIF-DES-BAS-8K-SEC-UID-S
Material: Novodur plastic
Max. operating temperature: 50 °C
Min. operating temperature: -25 °C
Programming technology: RFID (13,56 MHz)
RFID conformity: ISO 14443
RFID frequency: 13,56 MHz
RFID technology: MIFARE® DESFire® EV3
Reader type: MIFARE® DESFire® 8K EV3 (70pf)
Security features: Copy and read protection with MIFARE® DESFire® + ABUS security application with static UID
Transponder conformity: Passive transponder ISO 14443 A (MIFARE® DESFire®)
Transponder encryption: AES 128-Bit
Transponder programming: Access control software and card reader
