93RK/110 Monobloc

Recommended for hard-to-reach areas: our 93RK Monobloc padlock.

All variants for 93RK/110 Monobloc
Description
Want to secure a vending machine or rolling grille, but the spot is difficult to access?
Or you want to insure high-value and expensive items? Our 93RK Monobloc padlock is suitable for this purpose. The shackle and lock body are made of hardened special steel with Nano-Protect™ coating, making this padlock is extremely secure.
Awards & Partners
Test seal of the Svensk Brand- och Säkerhetscertifiering AB (class 5) – Stockholm, Sweden (SBSC)
SBSC Klasse 5
Test seal of the Svensk Brand- och Säkerhetscertifiering AB (class 5) – Stockholm, Sweden (SBSC)

CEN: Logo of the European norm for padlocks EN-12323 (class 6)
DIN EN 12320 KL 6
CEN: Logo of the European norm for padlocks EN-12323 (class 6)

Awards & Partners

Technologies

  • Shackle and lock body made of hardened special steel with NANO PROTECT™ coating for extra corrosion resistance
  • Protected against drilling or pulling open
  • Cylinder can be replaced and re-keyed to match an existing key
  • O: Accepts all standard oval cylinders
  • EPZ: Accepts all standard Euro profile half cylinders (Length: 10/30)
  • fig. 8: Accepts all cylinders from the ABUS 83 series
  • SSF Kl. 5/ CEN Kl. 6
  • Key retaining: key is needed for locking (lock retains key until locked)

Operation and use

  • To secure assets and objects of greater value or those at a high risk of theft
  • For the highest security requirements
  • For securing warehouses, factory gates, containers and lorries etc.

Downloads

General downloads:

Specifications
Locking type: key
Security card: No
Width a: 110 mm
Vertical clearance c: 21,5 mm
Depth e: 29 mm
Weight [g]: 1202 g
Security Level Home Security: 10
Design: Technical drawing
Technical drawing
type of cylinder: without cylinder
colour: silver
Horizontal clearance b: 34,5 mm
Shackle diameter d: 15 mm
Height f: 70 mm
Keyed alike: No
