Padlock Steel 83S/45 LFIC

83S/45 LFIC

The LFIC 83S/45 is the padlock of the flexible 83 series that we have manufactured especially for the North American market. The chrome-plated lock body made of hardened steel can accept standard LFIC cylinders.

All variants for LFIC 83S/45
Description
This padlock combines high resistance to theft attempts with great flexibility in its use. Do you want to be able to open many locks with just one key?
Thanks to its interchangeable cylinder, the LFIC 83S/45 allows you to create keyed-alike solutions. This means you only need one key for several tool cabinets in the shed or for doors and systems in the company. The padlock accepts standard Large Format Interchangeable Core cylinders. The shackle can also be easily and quickly exchanged for a smaller or larger shackle – depending on requirements.
Adaptable and secure
In addition to its flexibility, the LFIC 83S/45 impresses with a high level of security. The chrome-plated lock body is made of hardened steel and the shackle also resists all attempts to break open the lock with chrome-plated steel. The LFIC 83S/45 proves: a padlock can be tough as steel, secure and yet adaptable.

Technologies

  • Chrome-plated lock body made of hardened steel
  • Hardened and chrome-plated steel shackle
  • Double bolted locking mechanism increases the security of the lock
  • 2 variants: with automatic locking by simply pressing down the shackle or with key retaining, i.e. locking only with a key (key retaining is set up by inserting the Z-bar)
  • Rekeyable: the cylinder can be exchanged and thus also adapted to existing bittings
  • Shackle can be exchanged within seconds
  • “LFIC” version: accepts Large Format Interchangeable Core cylinders

Operation and use

  • Protection of items with a higher value and with a high risk of theft
  • Suitable for use on grilles, doors, gates, cabinets, toolboxes, cellar windows, sheds, switchgear, barriers, among other things
  • Extremely flexible: can be adapted to different requirements in a short time – thanks to its interchangeable cylinder and the possibility to quickly change the shackle

Downloads

General downloads:

Specifications
Locking type: key
Width a: 44,5 mm
Vertical clearance c: 30 mm
Depth e: 19 mm
Weight [g]: 369 g
Security Level Home Security: 8
Design: Technical drawing
Technical drawing
colour: silver
Horizontal clearance b: 23,5 mm
Shackle diameter d: 8 mm
Height f: 93 mm
Keyed alike: No
