Padlock brass 75/60 Lock-Tag Reversible key

75

The brass padlock 75 has an automatic locking system and a reversible key.

All variants for 75
Description
The brass padlock 75 has a reversible key.
Padlock 75 is great for securing doors, gates, cabinets, lockers, toolboxes, basements, sheds, switchgear, and more from theft. The lock body is made of solid brass, the shackle of hardened steel with NANO PROTECT™ corrosion protection. A high-precision locking mechanism is installed, which operates with a reversible key. To secure items of medium value or objects at moderate risk of theft, sizes 75/30 to 75/40 are suitable. For objects of higher value, or if the risk of theft is high, we recommend choosing a padlock between sizes 75/50 and 75/60. The 75IB variant is also weatherproof and therefore a sensible solution if you want to protect your belongings in sea and port areas.
Application example - Padlock brass 75
Awards & Partners
CEN: Logo of the European norm for padlocks EN-12320 (class 2)
DIN EN 12320 KL 2
CEN: Logo of the European norm for padlocks EN-12320 (class 2)

EC 75/40
Test seal of the Svensk Brand- och Säkerhetscertifiering AB (class 1) – Stockholm, Sweden (SBSC)
SBSC Klasse 1
Test seal of the Svensk Brand- och Säkerhetscertifiering AB (class 1) – Stockholm, Sweden (SBSC)

EC 75/40
Awards & Partners

Technologies

  • Solid lock body made from brass
  • Hardened steel shackle with NANO PROTECT™ plating for extreme corrosion resistance
  • Shackle made from hardened steel with NANO PROTECT™ plating
  • High precision reversible keyway with up to 150 000 key differs
  • Double bolted
  • Self-locking: locking without key by pushing down the shackle
  • Paracentric keyway for increased protection against manipulation
  • Inner components made from non-corrosive materials
  • 75IB/40 and 75IB/50: key-retaining

Operation and use

  • 75/30 - 75/40: To secure valuables/goods of medium value or at an average risk of theft
  • 75/50 - 75/60: To secure valuables/goods of greater value or at a high risk of theft
  • To secure doors, gates, cupboards, lockers, tool boxes, cellar windows, sheds, switchboards
  • 75IB: Ideal for use in coastal and port areas

Variants

  • Sizes: 30, 40, 50 and 60 mm
  • Rustfree (IB): 30, 40 and 50 mm
  • Long shackle (HB): 30HB30, 40HB40, 40HB63, 50HB50, 50HB80
  • Also availble with 5 keys

Downloads

General downloads:

Specifications
Locking type: key
colour: brass
Horizontal clearance b: 33 mm
Shackle diameter d: 10 mm
Height f: 90,5 mm
Keyed alike: No
Design: Technical drawing
Technical drawing
Security card: No
Width a: 60 mm
Vertical clearance c: 34,5 mm
Depth e: 19 mm
Weight [g]: 412 g
Security Level Home Security: 7
